【SPECIFICATIONS】
Poles: 2~20
Applicable wires: AWG28# ~22#
Applicable PC board thickness; 1.6mm
Temperature range: -25C~85C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance: ≤0.020
Insulation resistance: ≥1000MS
Withstand voltage: 1000V.AC/1min
【MATERIAL】
Housing: PA66 UL94V- 2(0)
Wafer: PA66 UL94V-2(0)
Terminal: Phos. bronze Tin/plated
