【SPECIFICATIONS】
Poles: (Y)1~22(A、WA)1~40
Applicable wires: AWG28#~22#
Applicable PC board thickness; 1.6mm
Temperature range: - 25C~859C
Voltage rating: 250V .AC/DC
Current rating: 3A
Contact resistance: ≤0.02
Insulation resistance: ≥1000MI
Withstand voltage: 1000V.AC/1min
【MATERIAL】
Housing:尼龙(PA66 ) UL94V-2(0)
Wafer: PBT UL 94V-2(0)
Terminal: Phos. bronze Tin/plated
