【SPECIFICATIONS】
Poles: 2~28
Applicable wires; AWG30# ~24#
Applicable PC board thickness: 1.2-1.6mm
Temperature range; - 25°C~85C
Voltage rating: 250V .AC/DC
Current rating: 2A
Contact resistance:≤0.020
Insulation resistance:≥1000M2
Withstand voltage: 800V.AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Terminal: Phos. bronze Tin/plated
