【SPECIFICATIONS】
Poles: 2~30
Applicable wires: AWG30# ~24#
Applicable PC board thickness: 1.2~ 1.6mm
Temperature range: -25C~859C
Voltage rating: 250V.AC/DC
Current rating: 2A
Contact resistance; ≤0.02
Insulation resistance: ≥1000MQ
Withstand voltage: 800V.AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Terminal : Phos bronze Tin/plated
