【SPECIFICATIONS】
Poles: 2~30
Applicable wires: AWG30# ~24#
Applicable PC board thickness: 1.6mm
Temperature range: - 25C~859C
Voltage rating: 250V.AC/DC
Current rating: 2A
Contact resistance:≤0.020
Insulation resistance:≥1000MS
Withstand voltage: 800V .AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Wafer: PA66 UL 94V-2(0)
Terminal; Phos bronze Tin/plated
