【SPECIFICATIONS】
Poles: 2~15
Applicable wires: AWG28# ~22#
Applicable PC board thickness; 1.6mm
Temperature range: - 25C~859C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance: ≤0.029
Insulation resistance: ≥1000MS
Withstand voltage: 1000V AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Wafer: LCP UL94V-2(0)
Terminal; Phos. bronze Tin/plated)
