【SPECIFICATIONS】
Poles: 2~23
Applicable wires: AWG28#~22#
Applicable PC board thickness: 1.2~ 1.6mm
Temperature range: -25C~859C
Voltage rating: 250V.AC/DC
Current rating: 2A
Contact resistance:≤0.029
Insulation resistance:≥1000MS
Withstand voltage; 1000V .AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Terminal: Phos. bronze Tin/plated
