【SPECIFICATIONS】
Poles: 2~16
Applicable wires; AWG28#~22#
Applicable PC board thickness: 1.6mm
Temperature range; -25C~85C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance: ≤0.020
Insulation resistance: ≥1000M2
Withstand voltage: 1000V AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Wafer: LCP UL94V-2(0)
Terminal; Phos.bronze Tin/plated
