【SPECIFICATIONS】
Poles: 2~30
Applicable wires: AWG28# ~22#
Applicable PC board thickness: 1.6mm
Temperature range: -25°C~85C
Voltage rating: 250V .AC/DC
Current rating: 3A
Contact resistance: ≤0.020
Insulation resistance: ≥1000M2
Withstand voltage: 1000V AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Wafer: PA66 UL94V-2(0)
Terminal; Phos bronze Tin/plated
