【SPECIFICATIONS】
Poles: 2~19
Applicable wires: AWG28# ~22#
Applicable PC board thickness: 1.6mm
Temperature range: -25C~85C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance:≤0.029
Insulation resistance:≥1000MS
Withstand voltage: 1000V AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Wafer: PA66 UL 94V-2(0)
Terminal; Phos. bronze Ti/plated
