【SPECIFICATIONS】
Poles: 2
Applicable wires: AWG28# ~22#
Applicable PC board thickness: 0.8~ 1.6mm
Temperature range: -25C~85C
Voltage rating: 1400V.AC/DC
Current rating; 1.0A
Contact resistance:≤0.029
Insulation resistance:≥1000M2
Withstand voltage: 3800V AC/1min
【MATERIAL】
Plug housing; PA66 UL94V-2(0)
Receptacle housing: PA66 UL94V-2(0)
Terminal: Phos. bronze Tin/plated
