【SPECIFICATION
Poles: 2~15
Applicable wires: AWG32# ~28#
Applicable PC board thickness: 0.8mm
Temperature range: - 25C~859C
Voltage rating: 125V.AC/DC
Current rating: 1A
Contact resistance: ≤0.032
Insulation resistance: ≥100MQ
Withstand voltage: 250V.AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Wafer: PA66 UL94V-2(0)
Terminal; Phos bronze Tin/plated
