【SPECIFICATIONS】
Poles:(YS)2~35x2(AS, WAS)2~40x2
Applicable wires: AWG28#~22#
Applicable PC board thickness: 1.6mm
Temperature range: -25C~85C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance: ≤0.02
Insulation resistance: ≥1000M2
Withstand voltage: 1000V.AC/1min
【MATERIAL】
Housing: PA66UL94V-2(0)
Wafer: PBT UL94V-2(0)
Terminal: Phos bronze Tin/plated
