【SPECIFICATIONS】
Poles; 2
Applicable wires; AWG26# ~20#
Applicable PC board thickness: 1.6mm
Temperature range: -25C~859C
Voltage rating: 250V.AC/DC
Current rating: 5A
Contact resistance: ≤0.0152.
Insulation resistance: ≥1000MS
Withstand voltage: 500V .AC/1min
【MATERIAL】
Housing: PA66 ) UL94V-2(0)
Wafer): PA66 ) UL94V-2(0)
Terminal : Phos bronze Tin/plated
