【SPECIFICATIONS】
Poles: 2~20
Applicable wires: AWG28#~22#
Applicable PC board thickness; 1.2~1.6mm
Temperature range: - 25C~859C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance:≤0.029
Insulation resistance:≥1000MS
Withstand voltage: 1000V.AC/1min
【MATERIAL】
Housing: PA66 UL94V- 2(0)
Terminal: Phos bronze Tin/plated
