【SPECIFICATIONS】
Poles: 2~28
Applicable wires: AWG30# ~24#
Applicable PC board thickness; 1.2~1.6mm
Temperature range: -25°C~85C
Voltage rating: 250V .AC/DC
Current rating: 2A
Contact resistance: ≤0.020
Insulation resistance: ≥1000MQ
Withstand voltage; 800V.AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Terminal: Phos bronze Tin/plated
