【SPECIFICATIONS】
Poles: 2~16
Applicable wires: AWG24#~ 18#
Applicable PC board thickness: 1.6mm
Temperature range: -25C~85C
Voltage rating: 250V .AC/DC
Current rating: 5A
Contact resistance:; ≤0.0152
Insulation resistance: ≥1000MS2
Withstand voltage: 1200V.AC/1min
【MATERIAL】
Housing:PA66 UL94V-2(0)
Wafer;PA66 UL94V-2(0)
Terminal: Phos. bronze Tin/plated
Brass Tin/plated
