【SPECIFICATIONS】
Poles: 2~18
Applicable wires: AWG28# ~22#
Applicable PC board thickness; 0.5~2.0mm
Temperature range: -25C~85C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance: ≤0.029
Insulation resistance: ≥800M2
Withstand voltage: 1000V AC/1min
【MATERIAL】
Plug housing: PA66 UL94V-2(0)
Receptacle housing:PA66 ) UL94V-2(0)
Retainer):PA66 UL94V-2(0)
Terminal: Phos.bronze Tin/plated
