【SPECIFICATIONS】
Poles: 2~15
Applicable wires: AWG30# ~24#
Applicable PC board thickness: 1.6mm
Temperature range: -25C~85C
Voltage rating: 250V.AC/DC
Current rating: 2A
Contact resistance: ≤0.029
Insulation resistance: ≥1000M2
Withstand voltage: 800V .AC/1min
【MATERIAL】
Plug housing; PA66 UL94V-2(0)
Receptacle housing:尼龙( PA66 ) UL94V-2(0)
Terminal; Phos. bronze Tin/plated
