【SPECIFICATIONS】
Poles: 2~15
Applicable wires: AWG32# ~28#
Applicable PC board thickness: 1.6mm
Temperature range: -25C~85C
Voltage rating: 50V.AC/DC
Current rating: 1A
Contact resistance:≤0.032
Insulation resistance:≥100MQ
Withstand voltage; 250V.AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Terminal: Phos. bronze Tin/plated
