【SPECIFICATIONS】
Poles): 1. 2、3、4、6、9、12、15
Applicable wires: AWG22#~ 16#
Applicable PC board thickness: 1.2~2.0mm
Temperature range; -25C~85C
Voltage rating: 300V.AC/DC
Current rating: 15Amax
Contact resistance: ≤0.012
Insulation resistance : ≥1000MQ
Withstand voltage: 1800V.AC/1min
【MATERIAL】
Plug housing: PA66 UL94V-2(0)
Receptacle housing: PA66 UL94V-2(0)
Terminal; Phos .bronze Tin/plated
