【SPECIFICATIONS】
Poles: 2~15
Applicable wires: AWG28#~22#
Applicable PC board thickness: 1.6mm
Temperature range: - 25C~859C
Voltage rating: 250V.AC/DC
Current rating: 3A
Contact resistance: ≤0.029
Insulation resistance: ≥1000MS
Withstand voltage; 1000V.AC/1min
【MATERIAL】
Plug housing: PA66 ) UL94V-2(0)
Receptacle housing: PA66 ) UL94V-2(0)
Terminal );磷青铜( Phos bronze Tin/plated
