【SPECIFICATIONS】
Poles: 2~15
Applicable wires: AWG32# ~28#
Applicable PC board thickness; 1.6mm
Temperature range: -25C~85C
Voltage rating: 125V .AC/DC
Current rating: 1A
Contact resistance: ≤0.039
Insulation resistance: ≥100MQ
Withstand voltage: 250V .AC/1min
【MATERIAL】
Housing: PA66 ) UL94V-2(0)
Wafer: LCP UL94V-2(0)
Terminal; Phos bronze Tin/plated
