【SPECIFICATIONS】
Poles: 1、2、3、4. 6、9、12、15
Applicable wires: AWG22#~ 18#
Applicable PC board thickness: 1.6mm
Temperature range: -25C~85C
Voltage rating: 300V.AC/DC
Current rating : 8Amax
Contact resistance: ≤0.0152
Insulation resistance: ≥1000MQ2
Withstand voltage: 1500V.AC/1min
【MATERIAL】
Plug housing: PA66 UL94V-2(0)
Receptacle housing: PA66 UL94V-2(0)
Terminal: Phos .bronze Tin/plated
