【SPECIFICATIONS】
Poles: 2、3、4、6、9、12、15
Applicable wires: AWG28#~ 18#
Applicable PC board thickness: 1.6~2.0mm
Temperature range: - 25C~859C
Voltage rating: 300V .AC/DC
Current rating: 10Amax
Contact resistance: ≤0.0152
Insulation resistance: ≥1000M2
Withstand voltage: 1500V AC/1min
【MATERIAL】
Plug housing; PA66 UL94V-2(0)
Receptacle housing: PA66 UL94V-2(0)
Retainer: PA66 UL94V-2(0)
Terminal: Phos.bronze Tin/plated
