【SPECIFICATIONS】
Poles: 2~24
Applicable wires: AWG28#~ 16#
Applicable PC board thickness; 1.6~2.0mm
Temperature range: -25C~85C
Voltage rating: 300V.AC/DC
Current rating: 9Amax
Contact resistance: ≤0.0152.
Insulation resistance; ≥1000M2
Withstand voltage: 1500V .AC/1min
【MATERIAL】
Plug housing: PA66 UL94V-2(0)
Receptacle honsing: PA66 UL94V-2(0)
Terminal; Phos. bronze Tin/plated
