【SPECIFICATIONS】
Poles; 2、3、4、12
Applicable wires: AWG24#~ 18#
Temperature range; - 25°C~85C
Voltage rating: 250V AC/DC
Current rating: 6A
Contact resistance: ≤0.0152
Insulation resistance: ≥1000MS
Withstand voltage ; 1500V.AC/1min
【MATERIAL】
Plug housing: PA66 UL94V-2(0)
Receptacle housing): PA66 UL94V-2(O)
Terminal: Phos. bronze Tin/plated
