【SPECIFICATIONS】
Poles: 2~15
Applicable wires: AWG32# ~28#
Applicable PC board thickness: 0.8~ 1.6mm
Temperature range: - 25°C~85°C
Voltage rating: 125V.AC/DC
Current rating; 1A
Contact resistance: ≤0.039
Insulation resistance: ≥100MQ
Withstand voltage; 250V.AC/1min
【MATERIAL】
Housing: PA66 UL94V-2(0)
Wafer: LCP UL94V-2(0)
Terminal：Phos. bronze Tin/plated
