【SPECIFICATIONS】
Poles: 2~12
Applicable wires: AWG28#~22#
Applicable PC board thickness; 1.6mm
Temperature range: -25C~85C
Voltage rating: 250V.AC/DC
Current rating: 5Amax
Contact resistance: ≤0.0159
Insulation resistance:≥1000MS
Withstand voltage; 1000V.AC/1min
【MATERIAL】
Plug housing: PA66 UL94V-2(0)
Receptacle housing: PA66 UL94V-2(0)
Terminal; Phos bronze Tin/plated
